China Wheel Loader with 3T Rated Load Capacity

1 / 5

China Wheel Loader with 3T Rated Load Capacity

Looking for a wheel loader for sale? Meet WINGS 3T front end loader is a heavy-duty machine with excellent load-handling capabilities. Configured like the CAT930, it features a Weichai 92kW high-torque diesel engine and a 3-ton capacity. Its efficiency and strength make it ideal for large urban projects, while its wheeled design enhances mobility for medium-sized jobs.

Send Inquiry

Product Description

Key Features

⚙️

Model: Wheel Loader with 3T Load Capacity - ZL30

⚖️

Total Weight: 10,000kg

🗑️

Standard Bucket Capacity: 1.8m³

🚀

Engine: Weichai diesel engine, 92kw

🛠️

Reliable Configuration: Fixed-axis gearboxes, simple structure, low failure rate, and stable performance.

🔄

Flexibility: Maintains balance while overloaded; high maneuverability for tight areas.

Applications

Urban Construction: Ideal for site preparation, material transport, and rubble handling in space-constrained urban environments.

Landscaping Operations: Compact design maneuvers through tight spaces for delicate plant care and soil moving.

Construction Site Versatility: Optimized lift capacity for carrying heavy building materials through rough terrain.

Main Parameters

Specification Detail		Unit	Data
Performance	Loader Lifting Capacity	kg	3000
	Operating Weight	kg	10000
	Rated Bucket Capacity	m³	1.8
	Max. Traction Force	kn	97
	Max. Breakout Force	kn	127
	Max Grade Ability	°	30°
	Max. Dump Height	mm	3100
	Max. Dump Reach	mm	1130
	Overall Dimension (L×W×H)	mm	7180×2350×3230
	Min Turning Radius	mm	6250
Engine	Model	-	Weichai
	Type	-	Inline, water cooled, four stroke
	Rated Power	kw	92
	Max. Torque	n.m	500
Hydraulic System	Working Pressure	mpa	16
	Boom Lifting Time	s	4.83
	Fuel Tank Capacity	l	170

Why Choose Our Solution?

✅ Works Everywhere: Handles even the toughest situations with superior stability.

✅ Built to Last: Designed for heavy-duty, long-term operational use.

✅ Global Support: Fast delivery of replacement parts worldwide to minimize downtime.

✅ Exceptional Value: High ROI through innovative technology and predictive maintenance.

Engineer efficiency with ZL30 – Excellent load-bearing capacity, flexible relocation!

Frequently Asked Questions (FAQ)

What is the maximum load capacity of the ZL30 loader?

The ZL30 wheel loader is designed with a robust 3,000kg (3T) rated lifting capacity, making it suitable for heavy-duty material handling.

What type of engine is used in this equipment?

It is powered by a high-performance Weichai diesel engine with a rated power of 92kw, ensuring reliable performance in various conditions.

Is this loader suitable for narrow urban spaces?

Yes, the ZL30 is specifically designed for flexibility and maneuverability, allowing it to access and operate effectively in space-constrained urban construction sites.

What is the standard bucket capacity?

The loader comes with a standard bucket capacity of 1.8m³, optimized for site preparation and transport of building materials.

What kind of braking system does the ZL30 feature?

The service brake is an air-assist disc brake acting on all 4 wheels, providing high safety and control during operation.

How does the transmission system contribute to its reliability?

It utilizes a fixed-axis gearbox mode with a simple and easy-to-maintain structure, resulting in a low failure rate and stable performance.
