China WINGS JS120 - Wheeled Skid Steer Loader Manufacturers, Suppliers

Powered by 103kW DEUTZ-Weichai turbo engine with 1.5T payload, features Rexroth hydraulic systems, climate-controlled cab, and precision pilot valves for extreme-condition snow removal/industrial handling.

Send Inquiry

Product Description

⚙️ Key Features

🔹

Model: WINGS JS120 (1.5T Wheeled Skid Steer Loader)

🔹

Total Weight: 3,600kg

🔹

Standard Bucket Capacity: 0.55m³

🔹

Engine: Weichai Deutz WP4.1G engine, 103kw

🔹

Euro-Asia Hybrid Powertrain: Weichai Deutz turbo engine paired with Rexroth German hydraulics ensures robust load handling and temperature-resistant operation.

🔹

Intuitive Multi-Role Design: Fast quick-attach system + climate-controlled cab enables seamless transitions between bulk material and precision tasks.

🏗️ Applications

Rugged Construction Sites: Handles heavy debris clearing and grading with reinforced bucket and terrain-adaptive tires.

Agricultural Material Logistics: Efficiently moves feed/fertilizers using high-flow hydraulics and auto-leveling valve stability.

Winter Urban Maintenance: Snowplow/road repair attachments thrive with cold-start capability and pressurized cabin comfort.

📊 Main Parameters

Specification
Performance	Model	-	JS120
	Rated Operating Capacity	KG	1500
	Tipping Load	KG	3000
	Bucket Capacity	m3	0.55
	Operating Weight	KG	3600
	Max. Travel Speed	km/h	12/18
	Hydraulic Pump Flow	L/min	80/140
	Fuel Tank Capacity	L	90
	Tires	-	12-16.5NHS
	Overall Dimensions	mm	358018802160
Dimensions	Height At Maximum Extension	mm	4070
	Height To Bucket Hinge Pin	mm	3150
	Width With Bucket	mm	2030
	Wheelbase	mm	1185
	Ground Clearance	mm	205
	Dump Angle	°	40°
	Dumping Height	mm	2450
Engine	Brand	-	Weichai Deutz
	Net Power	KW/rpm	103KW/2200rpm
	Type	-	4 Cylinder in-line, Water cooled
	Displacement	L	4.088

✅ Why Choose WINGS JS120?

Operational Versatility: Seamlessly transitions between buckets, augers, forks, and other attachments, excelling in farms, construction sites, and narrow urban alleys.

Reliable & Sturdy: Engineered with reinforced structures for sustained high-intensity cycles.

Rapid-Response Assurance: Global 72-hour parts delivery support and 24/7 technical guidance.

Cost-Smart Ownership: 12-month warranty + lifetime access to OEM-quality components at factory-direct pricing.

Command agility with WINGS JS120, the compact skid steer loader engineered for multi-attachment precision and space-defying productivity. Transform narrow worksites into power hubs.

❓ Frequently Asked Questions

What is the rated operating capacity of the JS120?

The JS120 has a rated operating capacity of 1,500 kg and a tipping load of 3,000 kg.

What kind of engine does this skid steer loader use?

It is powered by a high-performance Weichai Deutz WP4.1G engine, providing 103kw of power at 2200rpm.

Is the JS120 suitable for cold weather operations?

Yes, it features a preheating assist system specifically designed for extreme cold weather and a climate-controlled cab for operator comfort.

Can I use different attachments with this machine?

Absolutely. The machine is equipped with a fast quick-attach system and auxiliary hydraulic couplers to support buckets, augers, forks, and more.

What is the warranty period for the WINGS JS120?

The machine comes with a 12-month warranty and lifetime access to OEM-quality components at factory-direct pricing.

What are the hydraulic capabilities of this model?
